Probes (also known as horns) are solid titanium accessories for the Sonicator that process a range of different sample volumes. They come in many shapes and sizes. Using the appropriate size probe can greatly reduce processing times and ensure an entire sample is processed properly. The sample volume processed is directly related to the tip diameter. Smaller tip diameters are best for small samples, larger probes are required as sample volume increases.

SINO SONICS’s Homogenizer Kits provide everything you need to begin homogenizing based on your application.  Our Homogenizer Kits help you identify the necessary homogenizing equipment easier because they are process and/or volume range specific.

Homogenizing package kits are simplified into four categories: :

Micro-Sample Homogenizer: Focuses on using 0.5 ml ~20 ml test tubes
Small-Sample Homogenizer: Focuses on using 1.0 ml ~30 ml test tubes
Medium-Sample Homogenizer: Focuses on using 10 ml ~500 ml test beaker
Standard-Sample Homogenizer: Focuses on using 20 ml ~500 ml test beaker
Large-Sample Homogenizer: Focuses on using 3000 ml ~50 litre test barrel

With so many homogenizer options to choose from, let us help you quickly pick a high-quality homogenizer kit that includes everything you need to begin homogenizing. With over 11 years of experience, Sino Sonics knows what our customers need for their homogenizing applications.

Probe Tip
Diameter
Process
Volume Range
Amplitude
Microns
Probe
Length
Materials
final size
1/16″ (1.6 mm) 0.2 ml ~ 15 ml 320 μm 9 cm 2 ~3 nanometer
1/8″ (3.2 mm) 0.5 ml ~ 25 ml 180 μm 14 cm 3 nanometer
1/4″ (6.4 mm) 10 ml ~ 100 ml 120 μm 11 cm 3 nanometer
8.0 mm 10 ml ~ 200 ml 100 μm 11 cm 3 nanometer
9.0 mm 10 ml ~ 250 ml 90 μm 10 cm 4 nanometer
10.0 mm 20 ml ~ 300 ml 80 μm 10 cm 4 nanometer
1/2″ (12.7mm) 20 ml ~ 300 ml 60 ~ 120 μm 13 cm 3 ~5 nanometer
16.0 mm 20 ml ~ 600 ml 70 13 cm 5 nanometer
3/4″ (19.1mm) 50 ml ~ 800 ml 60 μm 28 cm 5 nanometer
20.0 mm 50 ml ~ 900 ml 55 ~80 μm 28 cm 7 nanometer
1″ (25.4mm) 100 ml ~ 1000 ml 35 μm 28 cm 7 nanometer
30.0 mm 100 ml ~ 3 litre 35 μm 30 cm 8 nanometer
40.0 mm 1000 ml ~ 25 litre 25 μm 30 cm 10 nanometer
50.0 mm  1000 ml ~ 30 litre 30 μm 50 cm 10 nanometer

* Depends on the frequency & probe design, the vibration amplitude will also change accordingly. however, the principle & philosophy is same.
* The processed material’s final size depends on the processing duration time, and material’s characteristics & propertites.
* The probe length & total length will be slightly different according to frequency & design.
* The process liquid volume can be 2x larger if the liquid solution thin enough.  (standard liquid: 50% oil + 50% water)
* The probe length & tip diameter are all customizable.
