35kHz 1200Watt Ultrasonic Generator
- CE Certified.
- Build in DSP chip control circuit, Japan’s capacitor, and high power output amplifier.
- Integrated full digital integrated circuit and the high performance anti-interference processor.
- Full-automatic frequency scanning, full-automatic frequency tracking, great working bandwidth.
- The output power is automatically adjusted according to the load, or maunally.
- Automatic error reporting, and prompts the fault display problem.
- Auto protection functions of transducer failure, overheating and load over current.
|Ultrasonic Generator Type||35kHz 1200Watt Ultrasonic Generator
|Generator Size:||250 mm x 360mm x 120mm|
|Net Weight:||4.3 Kgs, Gross weight: 5.0 Kgs|
|Working Frequency:||35 kHz (33 ~ 37 kHz)|
|Power in:||200 ~ 220V/ AC+/-10%, 50Hz ~ 60Hz|
|Power output:||120 ~ 1200 Watt (Tune from 10% – 100%)|
|Power out Voltage:||0-2500V (load)
|Working Temperature:||-5 to +50℃|
|Overcurrent protection Temp:||+85℃|
|Overcurrent protection current:||3A|
* Welding Mode: intermittent or continuous cutting/welding optional.
* Frequency adjustment period: Auto, smooth starting time:100ms
* Digital tracing frequency:Realtime & automatically
* Cooling fan integrated, designed for 24×7 heavy duty working.
* CE Certified
- 1) This machine is one of the most advanced equipment with the function of fully automatic welding. We developed a unique and excellent logic control frequency accuracy, wide tracking frequency, adaptive various types of transducers. No need to adjust frequency when changing molds/hone/probe/sonotrode when working.
- 2) Build an embedded processing sysIntem with a high-performance DSP as the core component, collect and process information in real time and efficiently, and perform related operations correctly. At the same time, it has strong scalability and can adapt to large-scale industrial applications.
- 3) Three Intelligent protection systems and fault alarm prompts: High mold current protection, frequency offset protection, large total output protection. If the equipment fails, the generator will immediately stop working and prompt the corresponding cause of the failure until the technician eliminates the failure.
- 4) It has three protection functions of transducer failure, overheating and load over current.
- 5) The intelligent ultrasonic generator equipped by Hongjin replaces the traditional triode with IGBT, which has the stronger power, shortens the welding time and reduces the failure rate.
- 6) It has the function of automatic error reporting, and prompts the fault display problem.
- 7) The output power is automatically adjusted according to the load or manually.
- 8) Full-automatic frequency scanning, full-automatic frequency tracking, great working bandwidth.
- 9) Hongjin intelligent ultrasonic generator uses the full digital integrated circuit and the high performance anti-interference processor imported from the United States, while reducing the number of components and simplifying the hardware structure, thereby improving the reliability of the system.
- 10) The application of the IGBT power module coupled with the structure of the other-excited oscillatory circuit makes the output power more than three times that of the traditional self-excited circuit.
- 11) Full-automatic frequency tracking and tuning, real-time display of the current frequency. Automatically tracking the best working state without manual tuning.
* Here we showcase a range of top-quality replacement components at super-low prices. These parts are fully compatible with the standard components from major manufacturers including Branson, Dukane, Telsonic, SoniKks and Rinco, Weber, these major manufacturers and constructed to equal (in many cases slightly improved) quality.
* We’re able to sell these ultrasonic parts at rock-bottom prices only because this is an automated operation with minimal overheads; we don’t offer help in selecting suitable parts for a particular application, rather, you are expected to know what you want and be able to specify it exactly. Generally this means that you already have ultrasonic equipment working and need replacement parts for spares or to replace worn or damaged items. Likewise if you need further information about these parts please see the other manufacturers’sites linked above.
* We supply transducer, also transducer with booster & horn. & We offer technical support, and welcome customer’s design.
for more information, please click Additional information tab, or consult our expert.
Telphone No.: +86-510-84390688, Mobile & WhatsApp: +86-170-0524-8000 or send us email.
|Dimensions||36 × 25 × 12 cm|
7 days after receiving payment
Inside Foam + Carton (Fedex /DHL Delivery)
Bank Transfer T/T for Order $500 & more, T/T or Paypal or West Union for Order less than $500
1 Year Warranty, Free Replacement
